STEEL Mini 4
Electric sauna heaters
Specifications
Heater
- Power rating (kW) 3,5
- Steam room min (m³) 3,5
- Steam room max (m³) 6
- Holding capacity of sauna rocks (kg) 60
- Weight (kg) 14,5
- Height (mm) 975
- Width (mm) 310
- Depth (mm) 160
Connection
- Fuse 16 A
- Supply voltage, 1-phase 1/N~230V
- Power cable (N x mm²) 3 x 2,5
230V 1N connection is analogous to a 3-phase connection. Division of heating circuits must precede the circuit breaker.
Safety distances
- A 50 mm
- B 420 mm
- C 310 mm
- D 160 mm
- H 975 mm
